Description

The Wall 63A is great when you need to pull a lot of power in a small space, and you are looking for a portable and compact solution that you can easily keep off the ground. With IP66 outlets and an IP67 inlets in a durable poly body, dust, dirt and water won’t be an issue for these rugged units.

Need something a little… more? Why not take a look at our Large Wall unit, or check out our full wall mounted range. If you can’t find something that suits your needs in our standard range, you can head to our Custom Bosbox builder to design your own board.

Standard model includes:

  • 1 x 63A 5 pin IP67 ceeform inlet
  • 1 x 63A 3 pole main circuit breaker
  • 6 x 15A 240V auto switched IP66 outlets
  • 6 x 16A RCBOs (for 15amp outlets)
  • 1 x 20A 415V 5 pin switched IP66 outlet
  • 1 x 32A 415V 5 pin switched IP66 outlet
  • 1 x 63A 4 pole RCD (for 415V outlets)
  • 1 x 20A 3 pole circuit breaker (for 20A outlet)
  • 1 x 32A 3 pole circuit breaker (for 32A outlet)

Additional information

Weight 18 kg
Dimensions 48 x 23 x 97 cm
Inlet Voltage

415V

Inlet Current

63A

Outlet Voltage(s)

415V, 240V

Outlet Current(s)

32A, 20A, 15A
