Wall Large

Description

When you need to keep your power board off the ground and a free standing unit isn’t an option, the Wall Large unit by Bosbox might just be what you’re looking for. This large 63A board can easily be mounted to the wall or taken down to provide power distribution wherever you need it. With everything you need from a 3 phase outlet RCD to an IP67 rated ceeform inlet, this board has got you covered.

Are the outlets on the Wall Large not quite what you are looking for? You can design your own custom board using our Custom Bosbox builder, to make sure you get exactly what you need.

Standard model includes:

  • 6 x 15A 240V auto switched IP66 outlets
  • 6 x 16A RCBOs (for 15A outlets)
  • 2 x 20A 5 pin switched IP66 outlets
  • 1 x 32A 5 pin switched IP66 outlet
  • 1 x 63A 4 pole RCD for 3 phase outlets
  • 2 x 20A 3 pole circuit breakers (for 20A outlets)
  • 1 x 32A 3 pole circuit breaker (for 32A outlet)
  • 1 x 63A 3 pole main IP66 switch
  • 1 x 63A 5 pin IP67 ceeform inlet



Additional information

Weight 25 kg
Dimensions 80 × 70 × 21 cm
Inlet Voltage

415V

Inlet Current

63A

Outlet Voltage(s)

415V, 240V

Outlet Current(s)

32A, 20A, 15A
